Quad VCA and CV Meter PCB's

PCB-layout for Quad VCA is ready. I designed also a PCB for MFOS CV-meter (from MFOS Multifunction module).

CV Meter is a very handy utility module that shows the CV level in three input ranges (+/-1, 5 or 10V). You get immediately a picture of what is the level and polarity of your modulating control voltage. My CV Meter layout is designed for EuroRack size. After I have double checked these I can order them from ITEAD Studio (

Quad VCA

CV Meter

CV Meter front panel
